技术参数

• Package / Case PowerPAK® 1212-8
• Mounting Type Surface Mount
• Operating Temperature -55°C ~ 150°C (TJ)
• Technology MOSFET (Metal Oxide)
• FET Type N-Channel
• Current - Continuous Drain (Id) @ 25°C 6A (Tc)
• Rds On (Max) @ Id, Vgs 58mOhm @ 5.4A, 10V
• Power Dissipation (Max) 3.2W (Ta), 19.8W (Tc)
• Vgs(th) (Max) @ Id 3V @ 250µA
• Supplier Device Package PowerPAK® 1212-8
• Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
• Vgs (Max) ±20V
• Drain to Source Voltage (Vdss) 60 V
• Gate Charge (Qg) (Max) @ Vgs 20 nC @ 10 V
• Input Capacitance (Ciss) (Max) @ Vds 665 pF @ 15 V
• ECCN EAR99
• HTSUS 8541.29.0095
• Moisture Sensitivity Level (MSL) 1 (Unlimited)
• REACH Status REACH Unaffected
• RoHS Status ROHS3 Compliant
